VMQN574T33-120.000-2.5/-40+85,MERCURY有源k1体育,VMQN574Tk1体育

频率：120MHz

尺寸：5.0 * 7.0 mm

Original model 原厂编码	VMQN574T33-120.000-2.5/-40+85
Manufacturer 品牌	MERCURYk1体育
Part Series 型号	MJF538D
Type 类型	VCTCXO
Frequency 频率	120MHz
Output Type 输出方式	CMOS
Supply Voltage 电压	3.3V
Frequency Stability 频率稳定性	±2.5ppm
Operating Temperature 工作温度	-40~85°C
Package Size 包装尺寸	5.0 * 7.0 mm

订购热线：13380314981

VMQN574T33-120.000-2.5/-40+85,MERCURY有源k1体育,VMQN574Tk1体育详细参数

Original model 原厂编码	VMQN574T33-120.000-2.5/-40+85
Manufacturer 品牌	MERCURYk1体育
Part Series 型号	MJF538D
Type 类型	VCTCXO
Frequency 频率	120MHz
Output Type 输出方式	CMOS
Supply Voltage 电压	3.3V
Frequency Stability 频率稳定性	±2.5ppm
Operating Temperature 工作温度	-40~85°C
Package Size 包装尺寸	5.0 * 7.0 mm
Package Height 厚度	2.5mm
Termination 脚位	4 pad
Package Type 封装类型	4-SMD
Lead Free 无铅	Yes
Mounting Style 安装方式	Surface Mount
Packaging 包装	Tape and Reel
