TYKTBLSANF-16.000000,TYk1体育,1.8Vk1体育,2520贴片k1体育,TAITIEN有源k1体育,泰艺石英晶体振荡器

频率：16MHz

尺寸：2.50mm x 2.00mm

Part Series 型号	TY
Original model 原厂编码	TYKTBLSANF-16.000000
Manufacturer 品牌	Taitien
Type 类型	TCXO
Frequency 频率	16MHz
Supply Voltage 电压	1.8V
Output Type 输出方式	削峰正弦波
Frequency Stability 频率稳定性	±1ppm
Package Size 包装尺寸	2520有源振荡器

订购热线：13380314981

TYKTBLSANF-16.000000,TYk1体育,1.8Vk1体育,2520贴片k1体育,TAITIEN有源k1体育,泰艺石英晶体振荡器详细参数

Part Series 型号	TY
Original model 原厂编码	TYKTBLSANF-16.000000
Manufacturer 品牌	Taitien
Type 类型	TCXO
Frequency 频率	16MHz
Supply Voltage 电压	1.8V
Output Type 输出方式	削峰正弦波
Frequency Stability 频率稳定性	±1ppm
Package Size 包装尺寸	2.50mm x 2.00mm
Termination 脚位	4 Pad
Package Height 厚度	0.80mm
Package Type 封装类型	4-SMDk1体育
Current Consumption 电流消耗	2mA
Operating Temperature 工作温度	-40°C ~ 85°C
Lead Free 无铅	Yes
Mounting Style 安装方式	Surface Mount
Packaging 包装	Tape and Reel
