当前位置：首页 » 台产k1体育 » DIODESk1体育 » FM3900001Z,DIODES佰利通,台产DIODESk1体育,2016mmk1体育,石英k1体育,石英贴片k1体育,DIODES佰利通k1体育
FM3900001Z,DIODES佰利通,台产DIODESk1体育,2016mmk1体育,石英k1体育,石英贴片k1体育,DIODES佰利通k1体育
频率：39.0625MHz
尺寸：2.00mm x 1.60mm
| Original model 原厂编码 | FM3900001Z |
| Part Series 型号 | SaRonix-eCera™ FM |
| Type 类型 | XO |
| Output Type 输出方式 | LVCMOS |
| Frequency 频率 | 39.0625MHz |
| Frequency Stability 频率稳定性 | ±50ppm |
| Supply Voltage 电压 | 3.3V |
| Manufacturer 品牌 | Diodes百利通k1体育 |
| Operating Temperature 工作温度 | -40°C ~ 85°C |
| Package Size 包装尺寸 | 2.00mm x 1.60mm |
订购热线：13380314981
FM3900001Z,DIODES佰利通,台产DIODESk1体育,2016mmk1体育,石英k1体育,石英贴片k1体育,DIODES佰利通k1体育 详细参数
| Original model 原厂编码 | FM3900001Z |
| Part Series 型号 | SaRonix-eCera™ FM |
| Type 类型 | XO |
| Output Type 输出方式 | LVCMOS |
| Frequency 频率 | 39.0625MHz |
| Frequency Stability 频率稳定性 | ±50ppm |
| Supply Voltage 电压 | 3.3V |
| Manufacturer 品牌 | Diodes百利通k1体育 |
| Operating Temperature 工作温度 | -40°C ~ 85°C |
| Package Size 包装尺寸 | 2.00mm x 1.60mm |
| Current Consumption 电流消耗 | 5mA |
| Package Height 厚度 | 0.85mm |
| Termination 脚位 | 4 Pad |
| Package Type 封装类型 | 4-SMD |
| Lead Free 无铅 | Yes |
| Mounting Style 安装方式 | Surface Mount |
| Packaging 包装 | Tape and Reel |
FM3900001Z,DIODES佰利通,台产DIODESk1体育,2016mmk1体育,石英k1体育,石英贴片k1体育,DIODES佰利通k1体育 相关产品
| NX3211C0125.000000 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±50ppm | -20°C ~ 70°C |
| NX3211C0125.000000 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±50ppm | -20°C ~ 70°C |
| NX3211C0125.000000 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±50ppm | -20°C ~ 70°C |
| FJ1600002 | Diodes百利通 | SaRonix-eCera™ FJ | 16MHz | ±50ppm | -20°C ~ 70°C |
| FJ1600002 | Diodes百利通 | SaRonix-eCera™ FJ | 16MHz | ±50ppm | -20°C ~ 70°C |
| FJ1600002 | Diodes百利通 | SaRonix-eCera™ FJ | 16MHz | ±50ppm | -20°C ~ 70°C |
| JX7011D0070.656000 | Diodes百利通 | SaRonix-eCera™ JX | 70.656MHz | ±25ppm | -40°C ~ 85°C |
| JX7011D0070.656000 | Diodes百利通 | SaRonix-eCera™ JX | 70.656MHz | ±25ppm | -40°C ~ 85°C |
| JX7011D0070.656000 | Diodes百利通 | SaRonix-eCera™ JX | 70.656MHz | ±25ppm | -40°C ~ 85°C |
| UJ2600007Z | Diodes百利通 | SaRonix-eCera™ UJ | 26MHz | ±20ppm | -20°C ~ 70°C |
| UJ2600007Z | Diodes百利通 | SaRonix-eCera™ UJ | 26MHz | ±20ppm | -20°C ~ 70°C |
| UJ2600007Z | Diodes百利通 | SaRonix-eCera™ UJ | 26MHz | ±20ppm | -20°C ~ 70°C |
| FJ1120001Z | Diodes百利通 | SaRonix-eCera™ FJ | 11.2896MHz | ±25ppm | -40°C ~ 85°C |
| FJ1120001Z | Diodes百利通 | SaRonix-eCera™ FJ | 11.2896MHz | ±25ppm | -40°C ~ 85°C |
| FJ1120001Z | Diodes百利通 | SaRonix-eCera™ FJ | 11.2896MHz | ±25ppm | -40°C ~ 85°C |
| FDC500026 | Diodes百利通 | SaRonix-eCera™ FD | 125MHz | ±50ppm | -20°C ~ 70°C |
| FDC500026 | Diodes百利通 | SaRonix-eCera™ FD | 125MHz | ±50ppm | -20°C ~ 70°C |
| FDC500026 | Diodes百利通 | SaRonix-eCera™ FD | 125MHz | ±50ppm | -20°C ~ 70°C |
| HX7011C0025.000000 | Diodes百利通 | SaRonix-eCera™ HX | 25MHz | ±25ppm | -40°C ~ 105°C |
| HX7011C0025.000000 | Diodes百利通 | SaRonix-eCera™ HX | 25MHz | ±25ppm | -40°C ~ 105°C |
| HX7011C0025.000000 | Diodes百利通 | SaRonix-eCera™ HX | 25MHz | ±25ppm | -40°C ~ 105°C |
| NX5011B0125.000000 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±25ppm | -20°C ~ 70°C |
| NX5011B0125.000000 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±25ppm | -20°C ~ 70°C |
| NX5011B0125.000000 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±25ppm | -20°C ~ 70°C |
| FNA000088Z | Diodes百利通 | SaRonix-eCera™ FN | 100MHz | ±50ppm | -40°C ~ 85°C |
| FNA000088Z | Diodes百利通 | SaRonix-eCera™ FN | 100MHz | ±50ppm | -40°C ~ 85°C |
| FNA000088Z | Diodes百利通 | SaRonix-eCera™ FN | 100MHz | ±50ppm | -40°C ~ 85°C |
| FNA000065 | Diodes百利通 | SaRonix-eCera™ FN | 100MHz | ±25ppm | -20°C ~ 70°C |
| FNA000065 | Diodes百利通 | SaRonix-eCera™ FN | 100MHz | ±25ppm | -20°C ~ 70°C |
| FNA000065 | Diodes百利通 | SaRonix-eCera™ FN | 100MHz | ±25ppm | -20°C ~ 70°C |
| NX71C50003 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±25ppm | -40°C ~ 85°C |
| NX71C50003 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±25ppm | -40°C ~ 85°C |
| NX71C50003 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±25ppm | -40°C ~ 85°C |
| FNC500131 | Diodes百利通 | SaRonix-eCera™ FN | 125MHz | ±50ppm | -40°C ~ 85°C |
| FNC500131 | Diodes百利通 | SaRonix-eCera™ FN | 125MHz | ±50ppm | -40°C ~ 85°C |
| FNC500131 | Diodes百利通 | SaRonix-eCera™ FN | 125MHz | ±50ppm | -40°C ~ 85°C |
| NX71C50001 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±20ppm | -20°C ~ 70°C |
| NX71C50001 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±20ppm | -20°C ~ 70°C |
| NX71C50001 | Diodes百利通 | SaRonix-eCera™ NX | 125MHz | ±20ppm | -20°C ~ 70°C |
| FM3900001Z | Diodes百利通 | SaRonix-eCera™ FM | 39.0625MHz | ±50ppm | -40°C ~ 85°C |
| FM3900001Z | Diodes百利通 | SaRonix-eCera™ FM | 39.0625MHz | ±50ppm | -40°C ~ 85°C |
| FM3900001Z | Diodes百利通 | SaRonix-eCera™ FM | 39.0625MHz | ±50ppm | -40°C ~ 85°C |
| FKA000018Z | Diodes百利通 | SaRonix-eCera™ FK | 100MHz | ±50ppm | -40°C ~ 85°C |
| FKA000018Z | Diodes百利通 | SaRonix-eCera™ FK | 100MHz | ±50ppm | -40°C ~ 85°C |
| FKA000018Z | Diodes百利通 | SaRonix-eCera™ FK | 100MHz | ±50ppm | -40°C ~ 85°C |
| HX3124501Q | Diodes百利通 | SaRonix-eCera™ HX | 24.545452MHz | ±25ppm | -40°C ~ 105°C |
| HX3124501Q | Diodes百利通 | SaRonix-eCera™ HX | 24.545452MHz | ±25ppm | -40°C ~ 105°C |
| HX3124501Q | Diodes百利通 | SaRonix-eCera™ HX | 24.545452MHz | ±25ppm | -40°C ~ 105°C |
| HX31330001 | Diodes百利通 | SaRonix-eCera™ HX | 33MHz | ±50ppm | -40°C ~ 90°C |
| HX31330001 | Diodes百利通 | SaRonix-eCera™ HX | 33MHz | ±50ppm | -40°C ~ 90°C |
| HX31330001 | Diodes百利通 | SaRonix-eCera™ HX | 33MHz | ±50ppm | -40°C ~ 90°C |
| HX3212F0040.000000 | Diodes百利通 | SaRonix-eCera™ HX | 40MHz | ±50ppm | -40°C ~ 105°C |
| HX3212F0040.000000 | Diodes百利通 | SaRonix-eCera™ HX | 40MHz | ±50ppm | -40°C ~ 105°C |
| HX3212F0040.000000 | Diodes百利通 | SaRonix-eCera™ HX | 40MHz | ±50ppm | -40°C ~ 105°C |
| SX10GE156 | Diodes百利通 | SaRonix-eCera™ ASSP XO™ | 156.25MHz | ±50ppm | -40°C ~ 85°C |
| SX10GE156 | Diodes百利通 | SaRonix-eCera™ ASSP XO™ | 156.25MHz | ±50ppm | -40°C ~ 85°C |
| SX10GE156 | Diodes百利通 | SaRonix-eCera™ ASSP XO™ | 156.25MHz | ±50ppm | -40°C ~ 85°C |
| HX3127001Q | Diodes百利通 | SaRonix-eCera™ HX | 27MHz | ±25ppm | -40°C ~ 105°C |
| HX3127001Q | Diodes百利通 | SaRonix-eCera™ HX | 27MHz | ±25ppm | -40°C ~ 105°C |
| HX3127001Q | Diodes百利通 | SaRonix-eCera™ HX | 27MHz | ±25ppm | -40°C ~ 105°C |
